Diff

Visual before-and-after comparison with a range controller

Diff

Import

@import "tailwindcss";
@import "@duskmoon-dev/core";

Individual CSS: @duskmoon-dev/core/components/diff.css (also available via the style export condition on @duskmoon-dev/core/components/diff). JavaScript import { css, styles } from "@duskmoon-dev/core/components/diff" exposes CSS text and a nullable CSSStyleSheet (null during SSR). It is not an interaction runtime.

Example

Mountain lake in daylightBefore
Mountain landscape under a different skyAfter
<figure class="diff" id="demo-diff" aria-label="Landscape comparison">
  <div class="diff-before"><img src="before.jpg" alt="Mountain lake in daylight"><span class="diff-label">Before</span></div>
  <div class="diff-after"><img src="after.jpg" alt="Mountain landscape under a different sky"><span class="diff-label">After</span></div>
</figure>
<label for="demo-diff-position">Before reveal</label>
<input class="range" id="demo-diff-position" aria-controls="demo-diff" type="range" min="0" max="100" value="50">

API And Accessibility

Semantic text variants: diff-primary, diff-secondary, diff-tertiary, diff-info, diff-success, diff-warning, diff-error. Keep meaningful labels and values; color alone is not an accessible distinction.

This is an image/content comparison, not a source-code diff editor. Classes: diff, diff-before, diff-after, diff-label, diff-static. Set --diff-position to 0%–100% (clamped), and --diff-ratio for stable sizing (16/9 default). Reveal follows inline direction in RTL. At 0% only After is visible; at 100% Before covers the full layer.

The range input supports pointer, touch and keyboard. It needs application wiring; CSS does not bind its value automatically:

const input = document.querySelector("#demo-diff-position");
const figure = document.querySelector("#demo-diff");
const update = () => figure.style.setProperty("--diff-position", `${input.value}%`);
input.addEventListener("input", update);
update();

Provide a label for the range, descriptive image alternatives and visible Before/After labels. Use diff-static for a side-by-side fallback without a controller. Print exposes both layers. Browsers without clip-path still display content but cannot reveal interactively; prefer the static variant. Keep layers noninteractive: visually clipped controls would remain focusable. Put actions outside the comparison.
